I am trying to use a RM520N-GL 5G HAT with my Vicharak Axon board.
The board detects the modem in lsusb, but I don’t see a usb0 network interface, so I cannot connect to the internet.
Could you please help with:
I just want to get a stable 5G data connection working.
Thanks!
Basically, For that you required driver.
sudo apt update
sudo apt upgrade
After that sudo reboot, in order to apply kernel into device.
Will Make guide for setting up 5G module.
Meanwhile you can explore using mmcli command.
Make sure Module is in USB mode,
You can be set it using below command.
Connect HAT To Axon and Attach Module in M.2 Connector.
Connect USB To Type-C Cable to Module to Axon USB and turn on Axon.
You can check usb devices are generated on tty like,
lsusb
sudo minicom -D /dev/ttyUSB2
Run below AT Commands.
AT+QCFG="data_interface",0,0
AT+QCFG="usbnet",1
Power off Axon.
Turn on Axon again and run mmcli -L.
Check on which device number module is detected, like
vicharak@vicharak:~$ mmcli -L
/org/freedesktop/ModemManager1/Modem/0 [Quectel] RM520N-GL
Check module applied is or not.
You cab check by running below command.
lsmod
Output can be liked below :
Module Size Used by
vicharak@vicharak:~$ lsmod
Module Size Used by
cdc_ether 24576 0
usbnet 40960 1 cdc_ether
option 65536 2
usb_wwan 24576 1 option
nfnetlink 20480 1
autofs4 45056 0
Check in more detailed.
mmcli -m 0
Output should be liked below :
vicharak@vicharak:~$ mmcli -m 0
-----------------------------------
General | path: /org/freedesktop/ModemManager1/Modem/0
| device id: 782621fa9a996a3c7fd80312ccfe2369c571b7dc
-----------------------------------
Hardware | manufacturer: Quectel
| model: RM520N-GL
| firmware revision: RM520NGLAAR03A03M4G
| carrier config: ROW_Commercial
| carrier config revision: XXXXXXXXX
| h/w revision: 20000
| supported: gsm-umts, lte, 5gnr
| current: gsm-umts, lte, 5gnr
| equipment id: XXXXXXXXXXXXX
-----------------------------------
System | device: /sys/devices/platform/fc880000.usb/usb3/3-1
| physdev: /sys/devices/platform/fc880000.usb/usb3/3-1
| drivers: option, qmi_wwan
| plugin: quectel
| primary port: cdc-wdm0
| ports: cdc-wdm0 (qmi), ttyUSB0 (ignored), ttyUSB1 (gps),
| ttyUSB2 (at), ttyUSB3 (at), wwan0 (net)
-----------------------------------
Status | lock: sim-pin2
| unlock retries: sim-pin (3), sim-puk (10), sim-pin2 (3), sim-puk2 (10)
| state: registered
| power state: on
| access tech: lte
| signal quality: 21% (recent)
-----------------------------------
Modes | supported: allowed: 3g; preferred: none
| allowed: 4g; preferred: none
| allowed: 3g, 4g; preferred: 4g
| allowed: 3g, 4g; preferred: 3g
| allowed: 5g; preferred: none
| allowed: 4g, 5g; preferred: 5g
| allowed: 4g, 5g; preferred: 4g
| allowed: 3g, 5g; preferred: 5g
| allowed: 3g, 5g; preferred: 3g
| allowed: 3g, 4g, 5g; preferred: 5g
| allowed: 3g, 4g, 5g; preferred: 4g
| allowed: 3g, 4g, 5g; preferred: 3g
| current: allowed: 4g; preferred: none
-----------------------------------
Bands | supported: utran-1, utran-4, utran-6, utran-5, utran-8, utran-2,
| eutran-1, eutran-2, eutran-3, eutran-4, eutran-5, eutran-7, eutran-8,
| eutran-12, eutran-13, eutran-14, eutran-17, eutran-18, eutran-19,
| eutran-20, eutran-25, eutran-26, eutran-28, eutran-29, eutran-30,
| eutran-32, eutran-34, eutran-38, eutran-39, eutran-40, eutran-41,
| eutran-42, eutran-43, eutran-46, eutran-48, eutran-66, eutran-71,
| utran-19, ngran-1, ngran-2, ngran-3, ngran-5, ngran-7, ngran-8,
| ngran-12, ngran-13, ngran-14, ngran-18, ngran-20, ngran-25, ngran-26,
| ngran-28, ngran-29, ngran-30, ngran-38, ngran-40, ngran-41, ngran-48,
| ngran-66, ngran-70, ngran-71, ngran-75, ngran-76, ngran-77, ngran-78,
| ngran-79
| current: utran-1, utran-4, utran-5, utran-8, utran-2, eutran-1,
| eutran-2, eutran-3, eutran-4, eutran-5, eutran-7, eutran-8,
| eutran-12, eutran-13, eutran-14, eutran-17, eutran-18, eutran-19,
| eutran-20, eutran-25, eutran-26, eutran-28, eutran-29, eutran-30,
| eutran-32, eutran-34, eutran-38, eutran-39, eutran-40, eutran-41,
| eutran-42, eutran-43, eutran-46, eutran-48, eutran-66, eutran-71,
| utran-19, ngran-1, ngran-2, ngran-3, ngran-5, ngran-7, ngran-8,
| ngran-12, ngran-13, ngran-14, ngran-18, ngran-20, ngran-25, ngran-26,
| ngran-28, ngran-29, ngran-30, ngran-38, ngran-40, ngran-41, ngran-48,
| ngran-66, ngran-70, ngran-71, ngran-75, ngran-76, ngran-77, ngran-78,
| ngran-79
-----------------------------------
IP | supported: ipv4, ipv6, ipv4v6
-----------------------------------
3GPP | imei: XXXXXXXXXXXXXXX
| enabled locks: fixed-dialing
| operator id: XXXXX
| operator name: IND airtel
| registration: home
| packet service state: attached
-----------------------------------
3GPP EPS | ue mode of operation: csps-2
| initial bearer path: /org/freedesktop/ModemManager1/Bearer/0
| initial bearer ip type: ipv4v6
-----------------------------------
SIM | primary sim path: /org/freedesktop/ModemManager1/SIM/0
| sim slot paths: slot 1: /org/freedesktop/ModemManager1/SIM/0 (active)
| slot 2: none
